Heat Exchanger Wheel Device
Enchoy:Your Professional Heat Exchanger Wheel Device Manufacturer!
Enchoy (Suzhou) Ventilation System Co., Ltd., a Sino-Finnish joint venture high-tech enterprise, is dedicated to promoting energy-saving and environmental protection concepts and improving living environments. It is a professional ventilation system equipment supplier that integrates research and development, production, testing, sales, and after-sales services. The company introduces leading Finnish manufacturing technology, follows European advanced management concepts and models, and combines domestic market demands to strengthen product research and development and quality control.
Why Choose Us
Our Product
Central fresh air system, haze removal fresh air machine, heat exchange fresh air machine, dehumidifier, humidifier, all-air integrated machine, rotary heat recovery fresh air machine, high-efficiency rotary heat recovery heat exchanger, cabinet-type total heat fresh air machine, constant oxygen total heat fresh air machine, mobile dehumidifier, duct fan.
Our Services
With rich experience and one-to-one service, we can help you choose products and answer technical questions. Provide extended warranty services to extend the equipment warranty period, allowing customers to use the products without worry.
Our Certificate
Enchoy (Suzhou) Ventilation System Co., Ltd. has passed multiple certifications including ISO9001:2015 Quality Management System Certification, ISO14001:2015 Environmental Management System Certification, 3C, and CE. A number of its product series have obtained national patent certificates.
Production Market
Collaborate with well-known decoration companies to create smart home supporting scenarios. Partner with large real estate developers to provide residential standard or value-added services. In the engineering market, provide centralized fresh air solutions for public buildings such as schools, hospitals, and office buildings.
Specification
|
Name |
Heat Exchanger Wheel Device |
|
Housing material |
Galvanized sheet |
|
Voltage |
220v/380v/customized |
|
Maximum Pressure Rating |
500Pa |
|
Dimension(l*w*h) |
Customized |
|
Airflow |
500-5000 |
|
Heat & energy recovery type |
Total heat & sensible heat |
|
Wheel thickness |
200mm |
|
Energy recovery efficiency |
70-90% |
High efficiency and energy saving: The heat exchanger wheel device can pre-cool and dehumidify in summer and pre-heat and humidify in winter by recovering the energy between indoor exhaust air and outdoor fresh air, thereby significantly reducing the cold and hot load and power consumption of air conditioners or boilers. Its recovery efficiency can reach more than 75%, effectively reducing energy consumption and operating costs.
Environmental protection: The heat exchanger wheel device does not produce any harmful substances during operation, so it is very environmentally friendly. Its structure is simple and not easy to damage, which reduces the frequency of repair and replacement of parts, and further reduces maintenance costs.
Simple maintenance: The heat exchanger wheel device has a simple structure and is easy to operate. It does not require professional maintenance and operation. Regular cleaning and maintenance can ensure its long-term stable operation and extend its service life.
Wide application: The heat exchanger wheel device is suitable for various places, including residences, offices, factories, etc., and can even be applied to the air conditioning system of cars.
Application of Heat Exchanger Wheel Device
Commercial HVAC Systems
Heat exchanger wheels are widely utilized in commercial HVAC systems, particularly in office buildings, shopping centers, and other large public spaces. In these environments, maintaining a comfortable indoor climate is crucial, but it can also be energy-intensive. By integrating energy recovery wheels into the HVAC system, these facilities can significantly reduce the energy required to condition the incoming air, leading to lower operational costs. The wheel’s ability to pre-condition air by recovering heat from the exhaust air stream ensures that less energy is needed to achieve the desired indoor temperature, making it an ideal solution for commercial settings with high ventilation demands.
Industrial Applications
In industrial settings such as factories, laboratories, and production facilities, the need for precise climate control is often combined with stringent energy efficiency requirements. Heat exchanger wheels are particularly effective in these environments, where large volumes of air need to be exchanged to maintain safe and comfortable working conditions. The wheels help to reduce the energy burden by transferring heat and moisture from the exhaust air to the incoming fresh air, ensuring that the HVAC system operates more efficiently. This is especially important in facilities that operate 24/7, where continuous energy savings can lead to significant cost reductions over time.
Special Environments
Heat exchanger wheels are also crucial in special environments like hospitals, schools, and other facilities with high ventilation needs. In hospitals, for example, maintaining strict indoor air quality standards is essential for patient safety and comfort. The ability of heat exchanger wheel device to control humidity and temperature while minimizing energy use makes them an invaluable component of hospital HVAC systems. Similarly, in schools and other educational institutions, where a healthy indoor environment is necessary for the well-being and productivity of students and staff, heat exchanger wheel device help ensure that air quality is maintained without excessive energy consumption.
Heat Exchange Matrix
This is the core component of the wheel, responsible for absorbing and releasing heat.It's typically made of corrugated or flat and corrugated materials like aluminum, plastic, or synthetic fiber. The matrix is designed to maximize surface area for efficient heat transfer.
Casing
The casing provides a housing for the rotating wheel and directs the airflow. It often includes sections for the intake and exhaust airstreams. Seals are incorporated to minimize air leakage between the two airstreams.
Drive System
A motor and belt drive system rotate the wheel. Inverter speed control can be used to regulate the wheel's speed and thus the heat transfer rate. The motor can be stopped when heat exchange is not needed.
Sealing Parts
Seals are crucial to prevent air leakage between the supply and exhaust airstreams.Various types of seals, such as brush seals or labyrinth seals, may be used.
Principle of Heat Exchanger Wheel Device
Basic working principle
The heat exchanger wheel relies on a heat storage element to transfer heat. The rotor rotates at a low speed (usually 1-10 rpm) and is filled with heat storage materials.
One part of the rotor passes through the hot airflow, and the other part passes through the cold airflow. When the hot airflow passes through the heat storage element, the element absorbs and stores heat, and the temperature rises; as the rotor rotates, the heat storage element enters the cold airflow area, releases the stored heat, preheats the cold airflow, and reduces its own temperature. The heat exchange cycle of the hot and cold airflows is completed once the rotor rotates one circle.
Heat exchange process
• Heating period: The heat storage element absorbs heat in the hot airflow and the temperature rises.
• Cooling period: The heat storage element releases heat in the cold airflow and the temperature decreases.
• Continuous heat exchange: The rotor rotates continuously, so that the cold and hot air flows can obtain continuous heat exchange.
Packaging and Shipping
